High Efficiency Rotary Magnetic Separator 24/7 Continuous Iron Removal For Automated Lines

Brand Name : M.Y

Model Number : MYXZ

Certification : ISO

Place of Origin : China

MOQ : 1

Price : 1-50000 USD

Payment Terms : Prepay 30%,70% of payment before shipping

Supply Ability : ＞100

Delivery Time : 25-60 Days

Packaging Details : Export Wooden

Housing Material : Carbon steel or 304 Stainless Steel

Viscosity Range : 1 - 50,000 cP (centipoise), requires high-power flushing system selection for high viscosity

Sealing System : Silicone sealing rings, Protection rating IP54

Magnetic System Type : Permanent Magnet Type

Cleaning Cycle : Adjustable, set based on iron content

Contact Now

Self-Cleaning Rotary Magnetic Separator

High Efficiency Rotary Magnetic Separator 24/7 Continuous Iron Removal For Automated Lines

Equipment Introduction: The self-cleaning rotary magnetic separator is centered on a rotating permanent magnet/electromagnetic roller set, paired with a synchronously operating flexible scraper or high-pressure purging device. When impurity-containing powder, granules, or slurry flows across the surface of the magnetic roller, ferromagnetic impurities are adsorbed by the strong magnetic field. As the magnetic roller rotates to the discharge zone, the cleaning device actively strips off the impurities, which then fall into the slag collection bin, while the purified material is discharged through the outlet. The entire adsorption-cleaning process cycles automatically without the need for shutdown or manual intervention.

Application Scenarios:

High-Capacity Powder Production Lines: Continuous iron removal for flour, feed, plastic pellets, and lithium battery cathode/anode powders, suitable for 24/7 uninterrupted automated production lines.
Food & Pharmaceutical Clean Fields: Iron removal for milk powder, pharmaceutical excipients, and health supplement granules, meeting GMP hygiene standards and avoiding material contamination from manual contact.
Non-Metallic Mineral Processing: Purification of quartz sand, kaolin, and ceramic raw material slurries to improve product whiteness and purity, compatible with wet grinding production lines.
Recyclable Resource Sorting: Iron removal for crushed waste plastic and rubber, efficiently separating ferromagnetic impurities to facilitate material recycling and reuse.
Fine Chemical Industry: Iron removal for pigments, coating powders, and catalyst particles, preventing metal impurities from affecting product color and chemical stability.

Advantages & Features:

Full Automation: The entire process (adsorption, discharge, cleaning) is completed automatically, eliminating the need for manual shutdown and disassembly cleaning. This significantly reduces labor costs and the risk of production line interruptions.
Thorough Cleaning with No Residue: The flexible scraper fits closely to the magnetic roller surface, stripping off stubbornly adsorbed micron-level impurities. This prevents impurity buildup (which causes magnetic field attenuation) and ensures stable iron removal efficiency.
Strong Material Adaptability: Capable of handling dry powder, granules, and low-viscosity slurries. The magnetic roller speed and magnetic field strength are adjustable to meet the iron removal needs of different materials.
Stable & Durable Operation: The magnetic roller surface is coated with wear-resistant and corrosion-resistant material. The cleaning device has low wear and low failure rates, making it suitable for long-term operation in harsh working conditions.
Excellent Sealing: The fully enclosed structure effectively prevents powder dust and slurry splatter, meeting the clean production requirements of the food, pharmaceutical, and similar industries.
